FRP C Channel Manufacturer | FRP U Channel Supplier Malaysia

FRP Boardwalk Deck, C-Channel Type (4 in and 6 in Wide)

FRP C-Channel 2C CC 50.8 x 25.4 x 4.76 mm (2 x 1 in, 4.76 mm Thick)

FRP C-Channel CC 64 x 24 mm (2-1/2 x 15/16 in, 3 and 5 mm Walls)

FRP C-Channel 3C CC 76.2 x 26.99 x 4.76 mm (3 x 1-1/16 in, 4.76 mm Thick)

FRP C-Channel 4C CC 101.6 x 41.28 x 4.76 mm (4 x 1-5/8 in, 4.76 mm Thick)

FRP C-Channel 4C CC 101.6 x 28.58 x 6.35 mm (4 x 1-1/8 in, 6.35 mm Thick)

FRP C-Channel 5C CC 139.7 x 38.1 x 6.35 mm (5-1/2 x 1-1/2 in, 6.35 mm Thick)

FRP C-Channel 6C CC 152.4 x 41.28 x 4.76 mm (6 x 1-5/8 in, 4.76 mm Thick)

FRP C-Channel 6C CC 152.4 x 41.28 x 6.35 mm (6 x 1-5/8 in, 6.35 mm Thick)

FRP C-Channel 6C CC 152.4 x 41.28 x 9 mm (6 x 1-5/8 in, 9 mm Thick)

FRP C-Channel 7C CC 177.8 x 50.8 x 6.35 mm (7 x 2 in, 6.35 mm Thick)

FRP C-Channel 8C CC 203.2 x 55.56 x 6.35 mm (8 x 2-3/16 in, 6.35 mm Thick)

FRP C-Channel 8C CC 203.2 x 55.56 x 9.53 mm (8 x 2-3/16 in, 9.53 mm Thick)

FRP C-Channels in Malaysia

Fiberglass (FRP) C-channels, also called U-channels, are used as beams, stair stringers, platform frames and supports in wet and corrosive sites. This range is part of our FRP Pultruded Profiles →.

Sizes

Channel	Depth x flange x thickness (mm)
2C →	50.8 x 25.4 x 4.76
2C (5 mm) →	64 x 24
3C →	76.2 x 27 x 4.76
4C →	101.6 x 41.3 x 4.76
4C →	101.6 x 28.6 x 6.35
5C →	139.7 x 38.1 x 6.35
6C →	152.4 x 41.3 x 4.76
6C →	152.4 x 41.3 x 6.35
6C →	152.4 x 41.3 x 9
7C →	177.8 x 50.8 x 6.35
8C →	203.2 x 55.6 x 6.35
8C →	203.2 x 55.6 x 9.53

We also make an FRP boardwalk deck in C-channel form: see the FRP boardwalk deck →.

Material and Finish

Process: pultruded E-glass rovings and mat with a surface veil that keeps glass fibres from the surface and improves UV and corrosion resistance
Resin: isophthalic polyester as standard; vinyl ester or fire-retardant (ASTM E84) on request
Colour: RAL 7035 light grey; other colours on request
Properties: light, rust free, non-conductive and resistant to chemicals and salt air

Where They Are Used

Platforms and walkways, cooling towers, handrails and ladders, wastewater plants, chemical plants, marine and coastal structures, and electrical areas where steel would rust or conduct.

Other Profile Shapes

How to Order

Tell us the profile, size, quantity and length you need. We can also cut and fabricate profiles into frames, supports and handrails. See all FRP pultruded profiles →.

Frequently Asked Questions

What do 2C to 8C mean?
The nominal depth in inches: 2C is about 2 in (50.8 mm) and 8C is 8 in (203.2 mm).

Which thickness should I choose?
Thicker sections (6.35 or 9.53 mm) for longer spans and heavier loads. Send us the span and load for advice.

What colour are they?
RAL 7035 light grey as standard.

Ringkasan: Saluran C FRP 2C hingga 8C (50.8 hingga 203.2 mm) untuk rasuk, rangka dan penyokong. Kalis karat.

Get a Quote →

FRP C-Channels
