FRP C-Channel 6C CC 152.4 x 41.28 x 4.76 mm (6 x 1-5/8 in, 4.76 mm Thick)
Pultruded FRP C-channel 6C, 152.4 mm deep x 41.3 mm flange (6 x 1-5/8 in), 4.76 mm thick. The lightest of our three 6 inch channels, for joists, frames and long light members. Rust free, RAL 7035 grey.
FRP C-Channel 6C CC 152.4 x 41.28 x 4.76 mm (6 x 1-5/8 in, 4.76 mm Thick)
The CC 152.4 x 41.28 x 4.76 is a pultruded fiberglass (FRP) C-channel (also called U-channel): depth x flange width 152.4 x 41.28 mm (6 x 1-5/8 in); thickness 4.76 mm (3/16 in). It is the lightest of our three 6 inch channels. It is made in Malaysia by Hexagon MF Composite Sdn Bhd, Mui Fatt's pultrusion sister company, in isophthalic polyester resin with a surface veil, in RAL 7035 light grey, and supplied by Mui Fatt.
Ringkasan: Saluran C FRP 6C, 152.4 x 41.3 mm (6 x 1-5/8 inci), tebal 4.76 mm, untuk gelegar dan rangka. Ringan dan tidak berkarat.
Specifications
| Model code | CC-152.4 x 41.28 x 4.76 |
|---|---|
| SKU | CC6-4 |
| Profile | C-channel (also called U-channel) |
| Depth x flange width | 152.4 x 41.28 mm (6 x 1-5/8 in) |
| Thickness | 4.76 mm (3/16 in) |
| Standard length | TBA (cut to length on request) |
| Weight per metre | TBA |
| Process | Pultrusion: E-glass rovings and mat with a surface veil |
| Resin | Isophthalic polyester (standard); vinyl ester on request |
| Fire-retardant option | Fire-retardant resin to ASTM E84 on request |
| Colour | RAL 7035 light grey; other colours on request |
| Made by | Hexagon MF Composite Sdn Bhd, Malaysia |
| Supplied by | Mui Fatt |
Material and Features
- Rust free: does not corrode in water, salt air or most chemicals
- Non-conductive: does not conduct electricity, safer near cables and electrical plant
- Light: much lighter than steel, so it is easy to carry and fit by hand
- Surface veil: keeps glass fibres below the surface and improves UV and corrosion resistance
- Easy to work: cut and drilled with standard power tools; seal cut edges with resin
Where It Is Used
- Joists and secondary beams
- Frames for walkways and covers
- Supports for cable ladders
- Purlins and rails in corrosive buildings
- Light stair stringers
Choosing This Size
All three 6C channels share the same 152.4 x 41.3 mm outline. This one has the thinnest wall (4.76 mm), so it gives depth and stiffness at the lowest weight.
Frequently Asked Questions
Is this channel 6C or 7C?
It is 6C: 152.4 mm (6 in) deep with a 41.3 mm flange. The 7C channel is CC 177.8 x 50.8 x 6.35.
Which 6C thickness should I choose?
4.76 mm for light members, 6.35 mm for most beams and 9 mm for heavy loads or many bolts. Send us the span and load.
Can you fabricate it into frames or supports?
Yes. We can cut and fabricate profiles into frames, supports and handrails. Send us a drawing or sketch.
Can it be cut and drilled on site?
Yes, with standard power tools. Wear a dust mask and seal cut edges and holes with resin to protect the fibres.
Berapa harga saluran C FRP CC 152.4 x 41.28 x 4.76?
Hubungi kami untuk harga terkini. Harga bergantung kepada saiz, panjang dan kuantiti.
Related Sizes and Products
Nearest sizes and related items: 6C, 6.35 mm →, 6C, 9 mm →, 5C, 139.7 x 38.1 x 6.35 →.
See every size in FRP C-Channels →.
