FRP C-Channel 6C CC 152.4 x 41.28 x 6.35 mm (6 x 1-5/8 in, 6.35 mm Thick)
Pultruded FRP C-channel 6C, 152.4 mm deep x 41.3 mm flange (6 x 1-5/8 in), 6.35 mm (1/4 in) thick. The mid-weight 6 inch channel, for platform beams, stair stringers and frames. Rust free, RAL 7035 grey.
FRP C-Channel 6C CC 152.4 x 41.28 x 6.35 mm (6 x 1-5/8 in, 6.35 mm Thick)
The CC 152.4 x 41.28 x 6.35 is a pultruded fiberglass (FRP) C-channel (also called U-channel): depth x flange width 152.4 x 41.28 mm (6 x 1-5/8 in); thickness 6.35 mm (1/4 in). It is the mid-weight 6 inch channel, often used for platform beams and stair stringers. It is made in Malaysia by Hexagon MF Composite Sdn Bhd, Mui Fatt's pultrusion sister company, in isophthalic polyester resin with a surface veil, in RAL 7035 light grey, and supplied by Mui Fatt.
Ringkasan: Saluran C FRP 6C, 152.4 x 41.3 mm (6 x 1-5/8 inci), tebal 6.35 mm, untuk rasuk platform dan rasuk tangga. Tidak berkarat dan tidak mengalirkan elektrik.
Specifications
| Model code | CC-152.4 x 41.28 x 6.35 |
|---|---|
| SKU | CC6-6 |
| Profile | C-channel (also called U-channel) |
| Depth x flange width | 152.4 x 41.28 mm (6 x 1-5/8 in) |
| Thickness | 6.35 mm (1/4 in) |
| Standard length | TBA (cut to length on request) |
| Weight per metre | TBA |
| Process | Pultrusion: E-glass rovings and mat with a surface veil |
| Resin | Isophthalic polyester (standard); vinyl ester on request |
| Fire-retardant option | Fire-retardant resin to ASTM E84 on request |
| Colour | RAL 7035 light grey; other colours on request |
| Made by | Hexagon MF Composite Sdn Bhd, Malaysia |
| Supplied by | Mui Fatt |
Material and Features
- Rust free: does not corrode in water, salt air or most chemicals
- Non-conductive: does not conduct electricity, safer near cables and electrical plant
- Light: much lighter than steel, so it is easy to carry and fit by hand
- Surface veil: keeps glass fibres below the surface and improves UV and corrosion resistance
- Easy to work: cut and drilled with standard power tools; seal cut edges with resin
Where It Is Used
- Beams for FRP platforms and walkways
- Stair stringers
- Frames for pump and valve access
- Supports for cable ladders and pipes
- Cooling tower framing
Choosing This Size
The 6.35 mm wall gives a good balance of strength and weight. It is a common choice for platform and walkway beams that carry FRP grating, and for stair stringers of moderate length.
Frequently Asked Questions
Can this channel carry FRP grating?
Yes. 6C channels are a common beam under FRP grating on platforms and walkways. Span and spacing depend on the load; we can check them.
What length can I order?
Standard length is TBA on this page. Tell us the lengths you need and we will confirm.
Can it be cut and drilled on site?
Yes, with standard power tools. Wear a dust mask and seal cut edges and holes with resin to protect the fibres.
Is a fire-retardant version available?
Yes. Profiles in fire-retardant resin to ASTM E84 are made on request. Vinyl ester resin is also available on request for stronger chemicals.
Berapa harga saluran C FRP CC 152.4 x 41.28 x 6.35?
Hubungi kami untuk harga terkini. Harga bergantung kepada saiz, panjang dan kuantiti.
Related Sizes and Products
Nearest sizes and related items: 6C, 4.76 mm →, 6C, 9 mm →, 7C, 177.8 x 50.8 x 6.35 →.
See every size in FRP C-Channels →.
