TruGrid Pultruded FRP Grating

TruGrid Pultruded FRP Grating in Malaysia

TruGrid is a pultruded fiberglass (FRP) grating for walkways, platforms, trench covers and stair landings in wastewater plants, chemical plants, oil and gas, offshore and construction sites. Pultruded I-shaped bearing bars are locked by a two-piece cross tie and bonded with structural adhesive, giving a flush top and high strength in the span direction. It comes in 25, 38 and 50 mm depths with 40% to 67% open area. TruGrid is made in Malaysia by Hexagon MF Composite Sdn Bhd and supplied by Mui Fatt. This range is part of our FRP Gratings →.

Models (bar depth and open area)

Model Depth Open area Notes
GTSL-38(67) → 38 mm 67% Slim bar, 30.5 mm bar centres, 17.6 kg/m²
GTSL-25(67) → 25 mm 67% Slim bar, 13.2 kg/m²
GTTW-25(40) → 25 mm 40% TW bar, 17.5 kg/m²
GTTW-25(50) → 25 mm 50% TW bar, 14.9 kg/m²
GTTW-25(60) → 25 mm 60% TW bar
GTTW-38(40) → 38 mm 40% TW bar
GTTW-38(50) → 38 mm 50% TW bar
GTTW-38(60) → 38 mm 60% TW bar
GTTW-50(40) → 50 mm 40% TW bar
GTTW-50(50) → 50 mm 50% TW bar
GTTW-50(60) → 50 mm 60% TW bar

GTSL = slim bar range with 30.5 mm bar centres and cross ties every 152.4 mm. GTTW = TW range in 40, 50 or 60% open area. Add (G) to the code for a gritted top, for example GTSL(G)-38(67).

Resin and Colour

  • Isophthalic polyester: grey, the standard for general corrosion resistance
  • Fire-retardant isophthalic: yellow
  • Vinyl ester: green, for strong chemicals

Panels, Surfaces and Fixing

  • Standard panel: 3 ft x 18 ft (914 x 5,486 mm), cut to size on request
  • Surface: smooth, or gritted with bonded quartz for anti-slip
  • Fixing: 316 stainless steel G, M and round clips
  • Load tables: span and deflection tables are in the TruGrid catalogue for design selection
  • SIRIM: TruGrid gratings carry a SIRIM certificate to BS 4592 Part 4; ask us for a copy.

Why pultruded instead of moulded? Pultruded bars are stronger along the span, so they suit longer spans and heavier foot traffic. For a lower-cost, two-way grating see MuiGrate moulded FRP grating →.

Frequently Asked Questions

What depths does TruGrid come in?
25, 38 and 50 mm bar depths, with 40%, 50%, 60% or 67% open area depending on the model.

What is the standard panel size?
3 ft x 18 ft (914 x 5,486 mm). Panels are cut to your layout.

Which resin should I choose?
Isophthalic (grey) for general use, fire-retardant isophthalic (yellow) where fire rating matters, and vinyl ester (green) for strong chemicals.

Ringkasan: Jeriji FRP pultrusi TruGrid, kedalaman 25, 38 dan 50 mm, kawasan terbuka 40 hingga 67%, resin isoftalik, kalis api atau vinil ester.
