FRP C-Channel 7C CC 177.8 x 50.8 x 6.35 mm (7 x 2 in, 6.35 mm Thick)

Pultruded FRP C-channel 7C, 177.8 mm deep x 50.8 mm flange (7 x 2 in), 6.35 mm thick. A deep channel with a 2 inch flange for longer beams and stair stringers. Rust free, RAL 7035 grey.

SKU :

CC7-6

FRP C-Channel 7C CC 177.8 x 50.8 x 6.35 mm (7 x 2 in, 6.35 mm Thick)

The CC 177.8 x 50.8 x 6.35 is a pultruded fiberglass (FRP) C-channel (also called U-channel): depth x flange width 177.8 x 50.8 mm (7 x 2 in); thickness 6.35 mm (1/4 in). It is a deep 7 inch channel with a 2 inch flange for longer spans. It is made in Malaysia by Hexagon MF Composite Sdn Bhd, Mui Fatt's pultrusion sister company, in isophthalic polyester resin with a surface veil, in RAL 7035 light grey, and supplied by Mui Fatt.

Ringkasan: Saluran C FRP 7C, 177.8 x 50.8 mm (7 x 2 inci), tebal 6.35 mm, untuk rasuk panjang dan rasuk tangga. Tidak berkarat.

Specifications

Model code	CC-177.8 x 50.8 x 6.35
SKU	CC7-6
Profile	C-channel (also called U-channel)
Depth x flange width	177.8 x 50.8 mm (7 x 2 in)
Thickness	6.35 mm (1/4 in)
Standard length	TBA (cut to length on request)
Weight per metre	TBA
Process	Pultrusion: E-glass rovings and mat with a surface veil
Resin	Isophthalic polyester (standard); vinyl ester on request
Fire-retardant option	Fire-retardant resin to ASTM E84 on request
Colour	RAL 7035 light grey; other colours on request
Made by	Hexagon MF Composite Sdn Bhd, Malaysia
Supplied by	Mui Fatt

Material and Features

Rust free: does not corrode in water, salt air or most chemicals
Non-conductive: does not conduct electricity, safer near cables and electrical plant
Light: much lighter than steel, so it is easy to carry and fit by hand
Surface veil: keeps glass fibres below the surface and improves UV and corrosion resistance
Easy to work: cut and drilled with standard power tools; seal cut edges with resin

Where It Is Used

Longer-span platform and walkway beams
Stair stringers for taller stairs
Main frames for access structures
Cable ladder and pipe rack beams
Cooling tower deck framing

Choosing This Size

The extra depth and the wider 50.8 mm flange make the 7C stiffer than the 6C channels, so it can span further between supports. The wide flange also gives good bearing for grating and room for bolts.

Frequently Asked Questions

7C or 8C?

The 8C channels are deeper (203.2 mm) for even longer spans. The 7C is lighter and suits moderate spans.

Why choose a deeper channel instead of a thicker one?

Depth adds stiffness faster than thickness, so a deeper channel usually deflects less over the same span.

Is a fire-retardant version available?

Yes. Profiles in fire-retardant resin to ASTM E84 are made on request. Vinyl ester resin is also available on request for stronger chemicals.

Why use FRP instead of steel?

FRP is much lighter than steel, does not rust, does not conduct electricity and resists many chemicals and salt air, so it needs little maintenance in wet or corrosive sites.
