FRP Lamination for Fertilizer Plant Equipment
FRP lamination for fertilizer plants is a fiberglass lining laid over mild steel handrails, I-beams, chemical tanks and other equipment to protect them from the chemicals and corrosive air in a fertilizer factory. Mui Fatt has lined mild steel equipment at a fertilizer factory in a clear (resin colour) or grey finish.
Ringkasan: Lapisan fiberglass (FRP) untuk peralatan kilang baja seperti pemegang tangan keluli, I-beam dan tangki kimia. Resin ISO atau vinyl ester melindungi keluli daripada bahan kimia dan karat. Kemasan jernih atau kelabu.
Specifications
| Lining build-up | 1 coat of resin primer, 2 to 5 plies of E-glass chopped strand mat (CSM), 1 ply of surface veil, 1 coat of waxed resin topcoat |
|---|---|
| Resin options | Isophthalic polyester (ISO) or vinyl ester (VE) |
| Substrate | Mild steel handrails, I-beams, chemical tanks and other plant equipment; concrete trenches, pits and bund walls |
| Finish | Clear (resin colour) or grey |
| Tests | Visual inspection for blisters, cracks, trapped air and irregularities; ply count during lamination (no thickness test) |
| Typical properties | Tensile strength 9,000 psi; tensile modulus 1,000,000 psi; Barcol hardness above 30; adhesion above 580 psi on grit-blasted steel and above 290 psi on sweep-blasted concrete |
How we line plant equipment
- Site visit: our technical staff check the equipment and access before work starts.
- Surface preparation: steel is ground to remove rust; concrete is blasted; dust is vacuumed off.
- Priming: a resin primer is brushed or rolled on and left until tacky.
- Lamination: 2 to 5 plies of glass mat are laid into wet resin and rolled, then a surface veil.
- Topcoat: a resin-rich waxed topcoat in clear or grey.
- Inspection: visual inspection for blisters, cracks and trapped air, with the plies counted as they are laid.
We work at 10°C to 50°C and relative humidity below 90%. No welding or cutting may take place near the lining area.
Applications in a fertilizer plant
- Mild steel handrails and I-beams
- Mild steel chemical tanks
- Trenches and pits
- Chemical spillage areas at concrete bund walls
Other FRP lamination pages
- FRP Lamination (FRP Lining) Service →
- FRP Lamination for Agitator Shafts, Impellers and Equipment →
- FRP Lamination for Mild Steel and Stainless Steel Tanks →
- FRP Lamination for Steel Structures →
Questions About Fertilizer Plant Lining
Can the plant keep running during the work?
Often yes, area by area, as long as no welding or cutting is done near the lining. We agree the sequence on the site visit.
Which finish colours are there?
Clear, which shows the resin colour, or grey.
Which resin do you use?
ISO or vinyl ester, chosen for the chemicals in your plant.
Berapa harga lapisan FRP untuk peralatan kilang baja?
Hubungi kami untuk harga terkini. Harga bergantung pada keluasan permukaan, bilangan lapis dan jenis resin.
