FRP Lamination for Roof Waterproofing

FRP lamination waterproofs concrete roofs and floors with one seamless layer of GP resin and glass mat, finished with a waxed topcoat. Laid by hand on site, usually 1 to 3 plies of 450 g/m² chopped strand mat.

SKU :

LAM-ROOF

Quantity :

FRP Lamination for Roof Waterproofing

FRP roof waterproofing is a seamless fiberglass layer of general purpose polyester (GP) resin and glass mat laid by hand on a concrete roof or floor. The glass mat bridges small cracks and the plies overlap into one continuous layer, so there are no joints for water to creep behind. Mui Fatt lays the lining on site.

Ringkasan: Kalis air bumbung dengan lapisan fiberglass (FRP) untuk bumbung dan lantai konkrit. Lapisan resin GP dan tikar gentian kaca ini tidak bersambung, jadi air tidak boleh meresap di celah sambungan. Kerja dibuat di tapak oleh pasukan kami.

Specifications

Substrate Concrete roofs and floors
Lining build-up 1 coat of resin primer; plies of 450 g/m² E-glass chopped strand mat (CSM); 1 ply of surface veil; 1 coat of waxed resin topcoat
Number of plies Minimum 1 ply recommended; usually up to 3 plies
Lining thickness About 1 mm per ply, so usually about 1 mm to 3 mm
Resin General purpose polyester (GP)
Colour Natural resin colour (clear) or grey
Typical properties Tensile strength 9,000 psi; tensile modulus 1,000,000 psi; Barcol hardness above 30; adhesion above 290 psi on sweep-blasted concrete
Curing Primer tacky in about 1 to 2 hours; each laminate stage touch dry in about 3 to 4 hours; topcoat left about 12 hours
Inspection Visual inspection for blisters, cracks, trapped air and irregularities; ply count during lamination
Work site On site

How we waterproof a roof

  • Site visit: our technical staff check the area, and access for workers, before work starts.
  • Surface preparation: the concrete is blasted to remove laitance and loose material, and dust is vacuumed off.
  • Priming: one coat of resin primer by brush or roller, left about 1 to 2 hours until tacky.
  • Levelling: small holes and unevenness are filled with FRP putty. Large concrete defects must be repaired by the owner first.
  • Lamination: each ply of glass mat is laid into wet resin, wetted through and rolled to remove trapped air, then the surface veil.
  • Topcoat: a resin-rich waxed topcoat, left to cure about 12 hours.
  • Inspection: visual inspection for blisters, cracks and trapped air, with the plies counted as they are laid.

Site conditions we need

  • New concrete: cured for about 28 days before lining.
  • Weather: 10°C to 50°C, relative humidity below 90%, surface at least 3 K above dew point, and no work in rain.
  • Access: the roof must be safely accessible for our workers.

Applications

  • Concrete house roofs
  • Concrete floors that must stay watertight

Other FRP lamination pages

Questions About Roof Waterproofing

Can the work be done in the rain?

No. The roof must be dry, and we do not laminate in rain. We plan the work around the weather.

Is FRP better than a waterproofing paint?

FRP is glass reinforced and millimetres thick, so it bridges small cracks that a thin paint film cannot. A paint coat costs less and may be enough for mild conditions.

Can I do a small roof myself?

Yes. We sell fiberglass chopped strand mat and waterproofing resin for small DIY jobs. Tell us your area and we will recommend what to buy.

Berapa harga kalis air fiberglass untuk bumbung?

Hubungi kami untuk harga terkini. Harga bergantung pada keluasan permukaan, bilangan lapis dan jenis resin.
