Insulated FRP/GRP Sectional Panel Water Tank (38mm PU Foam Panel)
FRP/GRP sectional panel water tank with 38 mm polyurethane (PU) foam insulated panels, for storing chilled or cold water and keeping its temperature. Built to the size you need.
Insulated FRP/GRP Sectional Panel Water Tank with 38 mm PU Foam Panels
The FRP-ST-INS-38 is an FRP/GRP sectional panel water tank with insulated panels: a polyurethane (PU) foam core between FRP skins, built to keep chilled or cold water at temperature. The standard foam thickness is 38 mm (1.5 inch), with 20 mm and 25 mm (1 inch) also available. Mui Fatt Marketing Sdn Bhd supplies it built to your size, and it is installed on site by our appointed sub-contractor.
Ringkasan
Tangki air panel FRP/GRP dengan panel bertebat: teras busa poliuretana (PU) di antara kulit FRP, untuk mengekalkan suhu air dingin atau sejuk. Ketebalan busa standard ialah 38 mm, dengan pilihan 20 mm dan 25 mm. Dibekal oleh Mui Fatt mengikut saiz anda dan dipasang di tapak oleh sub-kontraktor yang dilantik.
Specifications
| Model | FRP-ST-INS-38 |
|---|---|
| Panel build | PU foam core with FRP outer jacket |
| Insulation | Polyurethane (PU) foam, 38 mm (1.5 inch) standard; 20 mm or 25 mm (1 inch) on request |
| Jacket | About 2 mm FRP with gelcoat finish |
| FRP resin | Orthophthalic polyester with glass fibre |
| Process | Hand lay-up (contact moulding) |
| Colour | Blue (Mui Fatt standard) |
| Size | Built to order: length and width in 1 m steps, height to suit |
| Certification | SIRIM QAS (MS 1390:2010) and SPAN registration apply to the standard sectional panel tank |
| Installation | By our appointed sub-contractor on site; concrete plinth by the customer |
Where It Is Used
- Chilled water storage for air-conditioning and process cooling systems
- Cold water storage that must stay cool in hot rooftop or plant room locations
- Factories and food plants where water temperature affects the process
- Projects that need less condensation on the outside of the tank
Questions About the Insulated Tank
Why choose an insulated panel tank?
The PU foam slows heat gain from the sun and the surrounding air, so chilled water stays cold for longer and less energy is spent re-cooling it. It also reduces condensation dripping from the tank walls.
Is the insulated tank covered by SIRIM and SPAN?
The SIRIM QAS certificate to MS 1390:2010 and the SPAN registration are for the standard FRP sectional panel water tank. Ask us which documents apply to your insulated tank before you submit them.
Which insulation thickness do I need?
38 mm suits most chilled water tanks. Thinner 20 mm or 25 mm foam can be used where the water only needs to stay cool, not chilled. Tell us the water temperature and the site, and we will advise.
What do I prepare on site?
A level concrete plinth designed for the full tank load, plus access for delivery and hoisting. Piping and pumps can be added with our piping and pump service.
Berapa harga tangki air panel GRP bertebat 38 mm?
Harga bergantung kepada saiz, lokasi tapak, pemasangan dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini. Get a Quote →
Related Products
- Custom size FRP/GRP sectional panel water tank →
- Aluminium ladder for panel tanks →
- Panel tank installation service →
For materials, bracing, installation steps, warranty and certificates, see the full FRP/GRP Sectional Panel Water Tank guide. SPAN and SIRIM documents are on our certificate page.
