FRP Sectional Panel – Base Panel 1m x 1m
Loose FRP/GRP base (floor) panel, 1 m x 1 m, 5 to 9 mm thick, for sectional panel water tanks. Base panels come in 1 m x 1 m only because they carry the full water load. Made by Y.T. Fibreglass Industries.
FRP Base Panel 1 m x 1 m for Sectional Water Tanks
The FRP-SP-BASE-1x1 is a loose FRP/GRP base panel, 1 m x 1 m, used for the floor of every sectional panel water tank, sitting on the steel skid base. It is made by hand lay-up (contact moulding) by Y.T. Fibreglass Industries Sdn Bhd, the maker of Mui Fatt sectional panel water tanks certified to MS 1390:2010. Buy it to build a new tank, extend one, or replace a cracked or leaking panel.
Specifications
| Model | FRP-SP-BASE-1x1 |
|---|---|
| Panel type | Base Panel (floor) |
| Size | 1 m x 1 m |
| Thickness | 5 to 9 mm |
| Weight | At least 8 kg per panel |
| Material | FRP/GRP: unsaturated polyester resin with E-glass chopped strand mat and woven roving |
| Process | Hand lay-up (contact moulding) |
| Joint | Bolted flange with sealant gasket |
| Manufacturer | Y.T. Fibreglass Industries Sdn Bhd |
Panel Material Properties
| Specific gravity | 1.8 |
|---|---|
| Glass content | More than 30% |
| Tensile strength | 1,020 kg/cm² |
| Flexural strength | 1,650 kg/cm² |
| Compressive strength | 3,010 kg/cm² |
| Water absorption | Less than 0.2% |
| Light transmittance | Nil (blocks light, which helps prevent algae growth) |
Questions About This Panel
Why are base panels only 1 m x 1 m?
The base carries the full weight of the water, so it is made in the smaller 1 m x 1 m size with a thicker laminate for strength.
Will this panel fit my existing tank?
It fits Mui Fatt and Y.T. Fibreglass sectional tanks. For a tank from another maker, send us a photo, the panel size and the bolt hole spacing so we can check before you order.
Can you replace the panel for me?
Yes. Our team can drain the tank, exchange the panel and fit new gaskets and bolts. See panel tank refurbishment and panel exchange.
For materials, bracing, installation steps, warranty and certificates, see the full FRP/GRP Sectional Panel Water Tank guide. SPAN and SIRIM documents are on our certificate page.
