FRP Sectional Panel – Drain Panel 1m x 1m
Loose FRP/GRP drain panel, 1 m x 1 m, with a drain outlet, fitted in the base of a sectional panel water tank so it can be drained for cleaning. Made by Y.T. Fibreglass Industries Sdn Bhd.
FRP Drain Panel 1 m x 1 m for Sectional Water Tanks
The FRP-SP-DRAIN-1x1 is a loose FRP/GRP drain panel, 1 m x 1 m, used for the floor of a sectional tank, with a drain outlet so the tank can be emptied for cleaning. It is made by hand lay-up (contact moulding) by Y.T. Fibreglass Industries Sdn Bhd, the maker of Mui Fatt sectional panel water tanks certified to MS 1390:2010. Buy it to build a new tank, extend one, or replace a cracked or leaking panel.
Specifications
| Model | FRP-SP-DRAIN-1x1 |
|---|---|
| Panel type | Drain Panel (floor) |
| Size | 1 m x 1 m |
| Thickness | 5 to 9 mm |
| Weight | At least 8 kg per panel |
| Material | FRP/GRP: unsaturated polyester resin with E-glass chopped strand mat and woven roving |
| Process | Hand lay-up (contact moulding) |
| Joint | Bolted flange with sealant gasket |
| Manufacturer | Y.T. Fibreglass Industries Sdn Bhd |
Panel Material Properties
| Specific gravity | 1.8 |
|---|---|
| Glass content | More than 30% |
| Tensile strength | 1,020 kg/cm² |
| Flexural strength | 1,650 kg/cm² |
| Compressive strength | 3,010 kg/cm² |
| Water absorption | Less than 0.2% |
| Light transmittance | Nil (blocks light, which helps prevent algae growth) |
Questions About This Panel
Where is the drain panel placed?
In the base, usually at one corner, so the tank can drain fully. The drain outlet is then piped to a drain point on site.
Will this panel fit my existing tank?
It fits Mui Fatt and Y.T. Fibreglass sectional tanks. For a tank from another maker, send us a photo, the panel size and the bolt hole spacing so we can check before you order.
Can you replace the panel for me?
Yes. Our team can drain the tank, exchange the panel and fit new gaskets and bolts. See panel tank refurbishment and panel exchange.
For materials, bracing, installation steps, warranty and certificates, see the full FRP/GRP Sectional Panel Water Tank guide. SPAN and SIRIM documents are on our certificate page.
