Custom Size FRP/GRP Sectional Panel Water Tank
FRP/GRP sectional panel water tank built to the length, width and height you need, in 1 m and 1.5 m panel steps, from 1,000 to 500,000 litres. Send us your space and capacity for a quotation.
Custom Size FRP/GRP Sectional Panel Water Tank
The FRP-ST-CUSTOM is an FRP/GRP sectional panel water tank built to the length, width and height you need. Tanks are bolted together on site from 1 m x 1 m and 1 m x 1.5 m panels, so length and width change in 1 m steps and height in 0.5 m steps from 1 m to 4 m, from about 1,000 litres to over 500,000 litres. The panels are made by Y.T. Fibreglass Industries Sdn Bhd, the tank is SIRIM QAS certified to MS 1390:2010 and registered with SPAN, and Mui Fatt Marketing Sdn Bhd supplies and installs it across Peninsular Malaysia.
Ringkasan
Tangki air panel FRP/GRP dibina mengikut panjang, lebar dan tinggi yang anda perlukan: panjang dan lebar ikut langkah 1 m, tinggi 1 m hingga 4 m ikut langkah 0.5 m, dari sekitar 1,000 liter hingga lebih 500,000 liter. Panel buatan Y.T. Fibreglass Industries, diperakui SIRIM QAS (MS 1390:2010) dan berdaftar dengan SPAN. Dibekal dan dipasang oleh Mui Fatt di Semenanjung Malaysia.
Specifications
| Model | FRP-ST-CUSTOM |
|---|---|
| Size | Length and width in 1 m steps; height 1 m to 4 m in 0.5 m steps |
| Capacity | About 1,000 to over 500,000 litres |
| Panels | Base 1 m x 1 m; side 1 m x 1 m and 1 m x 1.5 m; roof 2 m x 1 m with a 1 m x 1 m manhole panel |
| Panel thickness | Base 5 to 9 mm, side 5 to 12 mm, roof from 4 mm |
| Standard | MS 1390:2010, SIRIM QAS certified; registered with SPAN |
| Supplied with | Steel skid base, air vent, internal and external aluminium ladder, FRP water level indicator |
| Warranty | 5 years outdoor, 10 years indoor; warranty certificate issued when installation is complete |
| Manufacturer | Y.T. Fibreglass Industries Sdn Bhd |
Panel Material Properties
| Specific gravity | 1.8 |
|---|---|
| Glass content | More than 30% |
| Tensile strength | 1,020 kg/cm² |
| Flexural strength | 1,650 kg/cm² |
| Compressive strength | 3,010 kg/cm² |
| Water absorption | Less than 0.2% |
| Light transmittance | Nil (blocks light, which helps prevent algae growth) |
What Is Included and What Is Not
- Included: supply of the tank and installation on site by our trained installers
- Not included: the concrete plinth that supports the tank
- Not included: plumbing such as overflow, scour valves and pipe runs, unless quoted separately
- Not included: mechanical pumps, which fall under the M&E package
Questions About Custom Sizes
How do I choose the size?
Start with the capacity you need and the floor space you have. For example, about 20,000 litres fits 5 m x 2 m x 2 m, or 4 m x 2 m x 2.5 m. Send us the space and capacity and we will propose the size.
Can I order a ready size instead?
Yes. Our standard sizes start from the 1,000 litre 1m x 1m x 1m tank and each has its own page in the guide below.
Can you add piping and pumps?
Yes, as a separate job. See our piping and pump service.
Berapa harga tangki air panel FRP saiz khas?
Harga bergantung kepada saiz, lokasi tapak, pemasangan dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini. Get a Quote →
Related Products
- Insulated sectional panel tank (PU foam) →
- Panel tank installation service →
- GRP sectional water tank replacement →
For materials, bracing, installation steps, warranty and certificates, see the full FRP/GRP Sectional Panel Water Tank guide. SPAN and SIRIM documents are on our certificate page.
Want to know more about this range? Our free water tank selection guide shows every PE and fiberglass tank at a glance, in seconds, with no details needed: Open the water tank selection guide →
Contact Mui Fatt for a quotation: Get a Quote →
