FRP Square Mesh Molded Grating 38 x 38 mm (25, 30, 38 and 50 mm)

MuiGrate FRP square mesh molded grating with 38 x 38 mm mesh and 69% open area, in four thicknesses: 25, 30, 38 and 50 mm. Compare panel weights and walkway spans to choose the right one.

SKU :

MG-SQ-38-RANGE

Quantity :

Send Whatapps

PDF download :

Download PDF

FRP Square Mesh Molded Grating 38 x 38 mm (25, 30, 38 and 50 mm)

FRP square mesh grating is MuiGrate molded fibreglass grating with a 38 x 38 mm square mesh and 69% open area, made in four thicknesses: 25, 30, 38 and 50 mm. The square mesh is equally strong in both directions, so panels can be laid either way and cut around pipes.

The thicker the grating, the further it spans between supports. Use the table below to pick a thickness, then open the model page for sizes, cut pieces and colours. All four are SIRIM certified to BS 4592-6:2008. Mui Fatt was the first maker of moulded FRP grating in Malaysia, and makes MuiGrate in Port Klang, Selangor.

Ringkasan: Jeriji FRP acuan jaring segi empat 38 x 38 mm MuiGrate, kawasan terbuka 69%, tebal 25, 30, 38 dan 50 mm. Diperakui SIRIM (BS 4592-6:2008).

Specifications

Mesh	38 x 38 mm square
Open area	69%
Thicknesses	25, 30, 38 and 50 mm
Standard panel	1,220 x 3,660 mm (4 x 12 ft); MG 38-38 also 1,527 x 4,000 mm
Resin	Orthophthalic, isophthalic or vinyl ester (most chemical resistant); fire-retardant version of each
Colour	Grey (standard), yellow, green
Surface	Concave anti-slip top; gritted on request
Standard	SIRIM product certification to BS 4592-6:2008, licence PC013894
Load use	Pedestrian traffic only (BS 4592)
Made by	Y.T. Fibreglass Industries Sdn Bhd, Port Klang

Choose a Thickness

Model	Thickness	Full panel weight	Walkway span (100 kg)
MG 25-38 →	25 mm	55 kg	up to 610 mm
MG 30-38 →	30 mm	67 kg	up to 914 mm
MG 38-38 →	38 mm	90 kg	up to 1,219 mm
MG50(38/38) →	50 mm	110 kg	up to 1,372 mm

Why FRP

One piece: no welds or joints, strong in both directions, easy to cut around pipes.
Light: 20.16 kg/m², easy to lift and fit by hand.
No rust, no scrap value: no corrosion in wet or salty areas, and nothing for thieves to sell.
Non-conductive: safe near electrical equipment.

Where It Is Used

Walkways and platforms
Drain and trench covers
Plant floors in wet and chemical areas

Questions and Answers

Which thickness should I use for a walkway?
25 mm grating on supports up to 610 mm apart, or 38 mm on supports up to 914 mm apart.

Square mesh or minimesh?
Square 38 x 38 mm is the general choice. Minimesh (20 x 20 mm on top) stops heels, trolley wheels and small items falling through.

Can it be cut to size?
Yes, at the factory to ±5 mm, up to a full panel.

Can vehicles drive on it?
No. MuiGrate FRP grating is designed for pedestrian traffic only, as BS 4592 sets out, not for cars, lorries or forklifts.

Berapa harga jeriji FRP segi empat?
Harga bergantung kepada saiz, kuantiti, warna dan resin. Hubungi Mui Fatt untuk sebut harga terkini.
