MuiGrate MG50(38/38) FRP Molded Grating 50 mm for Data Centre Cooling Tower Platforms
MuiGrate MG50(38/38) FRP molded grating, 50 mm thick, 38 x 38 mm mesh, 1,220 x 3,660 mm panel. Non-conductive and rust-free for data centre cooling tower platforms. SIRIM certified to BS 4592-6:2008.
MuiGrate MG50(38/38) FRP Molded Grating 50 mm for Data Centre Cooling Tower Platforms
The MuiGrate MG50(38/38) is our deepest FRP (fibreglass) molded grating: 50 mm thick with a 38 x 38 mm mesh, in 1,220 x 3,660 mm panels weighing 110 kg. It spans up to 1,372 mm between supports for foot traffic, the longest of the MuiGrate range, and is SIRIM certified to BS 4592-6:2008.
Data centre cooling towers run wet, warm and next to electrical plant. FRP does not rust in the spray, does not conduct electricity, and its open mesh lets air and water pass. Mui Fatt was the first maker of moulded FRP grating in Malaysia, and makes MuiGrate in Port Klang, Selangor.
Ringkasan: Jeriji FRP acuan MuiGrate MG50(38/38), tebal 50 mm, jaring 38 x 38 mm, panel 1,220 x 3,660 mm (110 kg), untuk platform menara penyejuk pusat data. Tidak berkarat, tidak mengalirkan elektrik. Diperakui SIRIM.
Specifications
| Model | MG50(38/38) |
|---|---|
| Type | MuiGrate FRP molded grating (one-piece open mesh) |
| Height (thickness) | 50 mm (2 in) |
| Mesh | 38 x 38 mm square |
| Open area | 69% |
| Standard panel | 1,220 x 3,660 mm (4 x 12 ft); cut to size |
| Weight | 110 kg per panel (24.63 kg/m²) |
| Resin | Orthophthalic, isophthalic or vinyl ester (most chemical resistant); fire-retardant version of each |
| Colour | Grey (standard), yellow, green |
| Surface | Concave anti-slip top; gritted on request |
| Standard | SIRIM product certification to BS 4592-6:2008, licence PC013894 |
| Load use | Pedestrian traffic only (BS 4592) |
| Made by | Y.T. Fibreglass Industries Sdn Bhd, Port Klang |
Support Span Guide (Pedestrian Use)
| Load | Maximum support span |
|---|---|
| 100 kg foot traffic | up to 1,372 mm |
| 500 kg | up to 1,219 mm |
| 1,000 kg | up to 914 mm |
Span is the clear gap between supports. Static loads at 1% deflection, safety factor 2.0. Pedestrian traffic only (BS 4592), not vehicles.
Why FRP
- Light: 24.63 kg/m², easy to lift and fit by hand.
- No rust, no scrap value: no corrosion in wet or salty areas, and nothing for thieves to sell.
- Non-conductive: safe near electrical equipment.
- Long spans: fewer support beams on wide platforms.
Where It Is Used
- Data centre cooling tower access platforms and walkways
- Chiller and plant room platforms
- Wide walkways with supports up to 1,372 mm apart
Questions and Answers
Why FRP for cooling tower platforms?
FRP does not rust in the constant wet, does not conduct electricity, and is light to lift onto roofs.
How far can MG50(38/38) span?
Up to 1,372 mm between supports for 100 kg foot traffic, 1,219 mm for 500 kg and 914 mm for 1,000 kg.
Is it SIRIM certified?
Yes. MuiGrate molded grating, including MG50(38/38), holds SIRIM licence PC013894 to BS 4592-6:2008.
Can vehicles drive on it?
No. MuiGrate FRP grating is designed for pedestrian traffic only, as BS 4592 sets out, not for cars, lorries or forklifts.
Berapa harga jeriji FRP MG50?
Harga bergantung kepada saiz, kuantiti, warna dan resin. Hubungi Mui Fatt untuk sebut harga terkini.
