MuiGrate Molded Grating Trench Cover, 25 mm (MG 25-38, 25-20, 25-100)

MuiGrate Molded Grating Trench Cover, 25 mm (MG 25-38, 25-20, 25-100)

MuiGrate FRP molded grating trench cover, 25 mm thick, in square (MG 25-38), minimesh (MG 25-20) or long mesh (MG 25-100), cut to fit drains and trenches with spans up to about 600 mm.

SKU :

MGZ

MuiGrate Molded Grating Trench Cover, 25 mm (MG 25-38, 25-20, 25-100)

The MuiGrate molded grating trench cover is 25 mm FRP (fibreglass) molded grating cut to the width and length of your drain or trench, for clear spans up to about 600 mm. Choose square mesh (MG 25-38), minimesh (MG 25-20) for small wheels and heels, or long mesh (MG 25-100) for fast drainage.

Covers are cut at our Port Klang factory to ±5 mm, are light to lift for cleaning and do not rust. For drains without a concrete recess, send us a photo and sizes and we suggest a fixing.

Ringkasan: Penutup parit jeriji FRP acuan MuiGrate 25 mm (jaring segi empat, mini atau panjang), dipotong ikut saiz longkang, rentang sehingga lebih kurang 600 mm. Tidak berkarat dan ringan.

Specifications

Models	MG 25-38 (38 x 38 mm), MG 25-20 (20 x 20 mm minimesh), MG 25-100 (25 x 100 mm)
Height (thickness)	25 mm (1 in)
Clear span	Up to about 600 mm (610 mm for 100 kg foot traffic)
Size	Cut to your drain, to ±5 mm; keep pieces to 1.5 m or shorter
Resin	Orthophthalic, isophthalic or vinyl ester (most chemical resistant); fire-retardant version of each
Colour	Grey (standard), yellow, green
Surface	Concave anti-slip top; gritted on request
Standard	SIRIM product certification to BS 4592-6:2008, licence PC013894
Load use	Pedestrian traffic only (BS 4592)
Made by	Y.T. Fibreglass Industries Sdn Bhd, Port Klang

Why FRP

Light: 12.32 kg/m², easy to lift and fit by hand.
No rust, no scrap value: no corrosion in wet or salty areas, and nothing for thieves to sell.
Non-conductive: safe near electrical equipment.
Anti-slip: concave top as standard; gritted top on request.

Where It Is Used

Roadside and walkway drains
Factory and plant trenches
Car porch and backyard drains (foot traffic only)

Questions and Answers

Which mesh should I choose?
Square 38 x 38 mm for general use, 20 x 20 mm minimesh where heels, trolleys or small items must not drop through, and 25 x 100 mm long mesh for the fastest drainage.

How wide a drain can it cover?
25 mm grating suits clear spans up to about 600 mm. For wider drains choose 30 or 38 mm grating.

How long should each piece be?
Keep pieces to 1.5 m or shorter so they lift out easily for cleaning.

Can vehicles drive on it?
No. MuiGrate FRP grating is designed for pedestrian traffic only, as BS 4592 sets out, not for cars, lorries or forklifts.

Berapa harga penutup longkang FRP?
Harga bergantung kepada saiz, kuantiti, warna dan resin. Hubungi Mui Fatt untuk sebut harga terkini.
