Mui Tank Closed Top Round FRP Water Tank, Custom Size up to 27,680 Gallon
Custom closed-top round fiberglass water tanks in 1.2 m to 4.0 m diameters, up to 27,680 gallons, made to your height and fittings. MS 1241-1:2011, SIRIM certified; SPAN registered up to 22,000 gallons.
Mui Tank Closed Top Round FRP Water Tank, Custom Size up to 27,680 Gallon
Mui Tank closed-top round fiberglass (FRP) water tanks come in six standard diameters from 1.2 m to 4.0 m, up to 27,680 imperial gallons. When a standard height or fitting layout does not suit your site, we make the tank to order within this range. Tanks are made by Y.T. Fibreglass Industries Sdn Bhd to MS 1241-1:2011 and SIRIM certified; tanks up to 22,000 gallons (100,000 litres) are registered with SPAN.
Ringkasan: Tangki air fiberglass (FRP) Mui Tank bertutup, bulat, saiz khas mengikut tapak anda, diameter 1.2 m hingga 4.0 m, sehingga 27,680 gelen. Mengikut MS 1241-1:2011 dan diperakui SIRIM. Tangki sehingga 22,000 gelen berdaftar dengan SPAN.
Standard Diameters
| Diameter | Capacity range (gal) | Maximum height (mm) |
|---|---|---|
| 1.2 m → | 250 to 750 | 3,000 |
| 1.5 m → | 400 to 1,460 | 3,750 |
| 2.0 m → | 700 to 3,460 | 5,000 |
| 2.4 m → | 1,000 to 5,980 | 6,000 |
| 3.0 m → | 2,000 to 11,680 | 7,500 |
| 4.0 m → | 5,000 to 27,680 | 10,000 |
Tanks of 3,000 gallons and above come with a level indicator and internal and external ladders.
Specifications
| Model | Mui Tank closed top, custom (SKU FRP-MT-CT-CUSTOM) |
|---|---|
| Type | Closed top, round, vertical |
| Diameters | 1.2, 1.5, 2.0, 2.4, 3.0 and 4.0 m |
| Capacity | Made to order, up to 27,680 gal |
| Material | Fiberglass reinforced unsaturated polyester (FRP), non-toxic, rust free, UV resistant |
| Standard | MS 1241-1:2011, SIRIM certified |
| Water authority | Registered with SPAN (up to 22,000 gallons) |
| Warranty | 8 years outdoor, 10 years indoor (cold water storage) |
| Manufacturer | Y.T. Fibreglass Industries Sdn Bhd |
| Supplier | Mui Fatt Marketing Sdn Bhd (ISO 9001:2015 certified) |
FRP Properties
| Tensile strength | 103 MN/m² (standard minimum 70) |
|---|---|
| Bending strength | 182.4 MN/m² (standard minimum 100) |
| Elastic modulus in bending | 7,906 MN/m² (standard minimum 6,000) |
| Barcol hardness | 50 |
| Water absorption | 0.15% (standard maximum 1.0%) |
Questions About This Tank
What is the largest Mui Tank?
The 4.0 m diameter closed-top tank at 10,000 mm high, holding 27,680 gallons.
Which tanks are registered with SPAN?
Mui Tanks up to 22,000 gallons (100,000 litres), the SPAN limit for this type of tank.
Can it be installed underground?
Closed-top Mui Tanks can be designed for underground use. Tell us the site conditions when you ask for a quote.
What do you need for a custom quote?
The capacity, the space available (diameter and height limits), where it will be installed, and the inlet, outlet, overflow and drain positions you need.
How is it installed?
Lift it only when empty, with a crane and rope or nylon slings on the lifting lugs, never by the pipe fittings. Place it on a level concrete platform at least 250 mm above ground, support all pipes on their own footings, keep it away from heat sources and fence the area.
Berapa harga tangki air fiberglass bertutup saiz khas?
Harga bergantung kepada saiz, kuantiti, lokasi penghantaran dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini.
See Also
For installation, care and how to choose between round, square and closed-top tanks, see the full Fiberglass Mui Tank guide →. Certificates are on our certificate page →
Note on units: All gallons on this page are imperial (UK) gallons. 1 m³ = 1,000 litres = 220 imperial gallons. A US gallon is smaller: 1 m³ is about 264 US gallons.
