FRP-CST FRP Caustic Soda (NaOH) Storage Tank, Made to Order

FRP tank for caustic soda (NaOH) and other alkaline liquids, made to your size. Round, 1 to 3 m diameter, vinyl ester resin with a resin-rich inner liner, built by Y.T. Fibreglass Industries Sdn Bhd.

SKU :

FRP-CST

Quantity :

FRP-CST FRP Caustic Soda (NaOH) Storage Tank, Made to Order

The FRP-CST is a fiberglass (FRP/GRP) tank built to store caustic soda (sodium hydroxide, NaOH) and other alkaline liquids. Each tank is made to your size and drawing by Y.T. Fibreglass Industries Sdn Bhd, with the resin and inner liner matched to the chemical, its concentration and its temperature. The FRP body does not rust, so it suits chemical dosing areas in water and wastewater plants and factories.

Ringkasan: Tangki simpanan soda kaustik (NaOH) FRP gentian kaca dibuat mengikut saiz dan lukisan pelanggan. Resin dan lapisan dalam dipilih mengikut bahan kimia, kepekatan dan suhu. Tidak berkarat, sesuai untuk loji rawatan air, air sisa dan kilang.

Specifications

Model FRP-CST (made to order)
Stored liquid Caustic soda (NaOH) and other alkaline liquids; confirmed per enquiry
Material FRP (GRP), glass-fibre reinforced vinyl ester or polyester, matched to the chemical
Shape Round, vertical, closed or open top
Diameter 1 m to 3 m (4 m subject to road access)
Height and capacity TBA, made to your drawing
Inner liner Resin-rich corrosion barrier with veil; hybrid build (vinyl ester inside, polyester outside) available
Design standard Designed to BS 4994 / BS EN 13121 and ASTM D3299; engineering calculation on request
Working temperature Vinyl ester about 40°C to 75°C, depending on the chemical and concentration
Nozzle flanges Standard HDPE flanges; FRP flanges on request
Base Level concrete plinth at least 250 mm (10 in) above ground
Options Manhole, cover, vent, overflow, level indicator, fiberglass ladder, railing
Lead time Typically 7 to 14 working days, subject to production schedule
Warranty 1 year standard; extended warranty on request
Manufacturer Y.T. Fibreglass Industries Sdn Bhd

Why FRP for Caustic Soda

  • No rust: FRP does not corrode like mild steel, so there is no rust flake in the dosing line.
  • Resin chosen for the chemical: vinyl ester resin is used for strong alkalis and acids; polyester for milder liquids.
  • Protective inner layer: a resin-rich liner sits between the chemical and the structural glass layers.
  • Seamless round body: filament wound in one piece, then laminated, so there are no panel joints.
  • Light to handle: easier to lift and place than a steel or concrete tank of the same size.

Typical Uses

  • Caustic soda dosing and pH correction in water and wastewater treatment plants
  • Chemical storage in soap, detergent, textile and paper factories
  • Cleaning chemical (CIP) holding tanks in food and beverage plants

Questions and Answers

Which resin is used for a caustic soda tank?

Usually vinyl ester resin with a resin-rich inner liner. We confirm the resin for every order from the concentration and temperature you give us.

What size can you make?

Round tanks from 1 m to 3 m in diameter, and 4 m where road access allows. Height and capacity are made to your drawing.

Is this tank registered with SPAN or SIRIM?

No. SIRIM and SPAN registration covers our Mui Tank cold water tanks only. Chemical tanks are designed to BS 4994 / BS EN 13121 and ASTM D3299, with engineering calculation on request.

What do you need from me for a quote?

The chemical and its concentration, the working temperature, the volume or drawing, nozzle positions, and options such as manhole, ladder or level indicator.

Berapa harga tangki soda kaustik FRP?

Harga bergantung pada saiz, resin dan aksesori. Hubungi Mui Fatt untuk sebut harga terkini.
