FRP Round Open-Top Tank with Conical Base and Support
Cone-bottom FRP tank on a support stand, used as a clarifier, bio tank, coagulation tank and PAC chemical holding tank. Diameter 1 m to 3 m, built to your drawing with the resin matched to the liquid.
FRP Round Open-Top Tank with Conical Base and Support - Clarifier and PAC Tank
An FRP round open-top tank with a conical bottom, standing on its own support frame. The cone gathers settled solids at one outlet for easy draw-off, which is why wastewater treatment contractors use it as a clarifier, bio tank, coagulation tank and PAC chemical holding tank. In Malay it is often searched as tangki PAC FRP.
Ringkasan: Tangki FRP (gentian kaca) bulat, atas terbuka, dengan dasar kon dan rangka penyokong, untuk penjernih, tangki bio dan simpanan kimia PAC. Diameter 1 m hingga 3 m, tinggi mengikut lukisan anda.
Key Features
- Cone bottom: settled solids collect at one bottom outlet.
- Support stand: bare mild steel, mild steel laminated with FRP, or pultruded FRP.
- Seamless body: filament wound in one piece, then laminated.
- Resin matched to the liquid: GP, ISO or vinyl ester.
- Built to your drawing: diameter, height and nozzles made to suit your plant.
Specifications
| Model | FRP-RT-CB |
|---|---|
| Material | FRP (GRP), glass-fibre reinforced polyester or vinyl ester |
| Shape | Round, open top, flanged rim, conical base |
| Dimensions | Diameter 1 m to 3 m (4 m subject to road access); height to your drawing |
| Support | Four-leg stand: bare mild steel, FRP-laminated mild steel or pultruded FRP |
| Typical fittings | Side nozzles, cone-bottom outlet, lifting lugs |
| Construction | Filament wound body, then laminated |
| Design standard | Designed to BS 4994 / BS EN 13121 and ASTM D3299; engineering calculation on request |
| Corrosion barrier | Optional resin-rich inner layer with polyester veil, or hybrid build with vinyl ester inside and GP outside |
| Working temperature | GP resin 25°C to 40°C. Vinyl ester about 40°C to 75°C, depending on the chemical |
| Nozzle flanges | Standard off-the-shelf HDPE flanges; FRP flanges on request |
| Options | Cover, fiberglass ladder, railing |
| Quality checks | Barcol hardness test, thickness check and leak test on every tank before delivery |
| Warranty | 1 year standard; extended warranty on request |
Example Capacities
| Diameter | Straight wall | Volume above the cone |
|---|---|---|
| 1 m | 1 m | about 790 L |
| 2 m | 2 m | about 6,300 L |
| 3 m | 3 m | about 21,200 L |
Volumes are approximate and for guidance only. Every tank is built to your sizes.
Applications
- Clarifier
- Bio tank
- Coagulation tank
- PAC chemical holding tank
Resin Selection
- GP (orthophthalic polyester): for water and mild, non-aggressive liquids.
- ISO (isophthalic polyester): a premium polyester with good chemical resistance.
- Vinyl ester: for severe corrosion, including strong acids and alkalis. For solvents, tell us the chemical and we will confirm.
- Hybrid: vinyl ester inside for chemical resistance, GP outside for economy.
Laminate Strength
Test results for the GP laminate used in our Mui Tank range: 103.0 MPa tensile strength (limit 70 min), 182.4 MPa bending strength (limit 100 min) and 0.15% water absorption (limit 1.0 max). Chemical-grade laminate data is available on request.
Installation
- Sit the tank stand on a level concrete plinth at least 250 mm (10 in) above ground.
- Lift only when empty, using the lifting lugs.
- Support every connecting pipe and valve on its own footing.
What to Tell Us for a Quote
- The chemical or liquid, its concentration and its temperature
- Tank size or drawing, and nozzle positions
- Support type and options such as cover, ladder or railing
FAQ
Why a conical bottom? Settled solids slide to one bottom outlet, so they can be drawn off without emptying the tank.
Which support stand should I choose? Bare mild steel is the most economical. FRP-laminated mild steel or pultruded FRP suits corrosive areas.
Can it be used for PAC? Yes. It is often ordered as a PAC chemical holding tank.
Berapa harga tangki PAC FRP dasar kon? Harga bergantung kepada saiz, resin dan pilihan tambahan. Hubungi Mui Fatt untuk sebut harga terkini.
Adakah Mui Fatt menghantar ke seluruh Malaysia? Ya. Kami menghantar ke seluruh Semenanjung Malaysia, dan ke Sabah serta Sarawak melalui ejen penghantaran. Tempoh siap biasanya 7 hingga 14 hari bekerja.
Ordering and Delivery
Lead time is typically 7 to 14 working days, subject to the production schedule. We deliver across Peninsular Malaysia, and to Sabah and Sarawak through a freight agent. Manufactured by Y.T. Fibreglass Industries Sdn Bhd, a Mui Fatt subsidiary.
Contact Mui Fatt for a quotation: Get a Quote →.
