FRP Round Open-Top Tank, Flat Base
Round open-top FRP tank with a flat base for holding pre-treatment water and sludge water in wastewater treatment plants. Diameter 1 m to 3 m, built to your drawing and set on a concrete plinth.
FRP Round Open-Top Tank, Flat Base - Simple Holding Tank for Wastewater Plants
An FRP round open-top tank with a flat base, used to hold pre-treatment water, sludge water and other liquids in a wastewater treatment plant. The body is filament wound in one piece, so there are no panel joints to leak, and the resin is matched to the liquid it will hold. In Malay it is often searched as tangki air sisa FRP.
Ringkasan: Tangki air sisa FRP (gentian kaca) bulat, atas terbuka, dasar rata, untuk air pra-rawatan dan air enap cemar di loji rawatan air sisa. Diameter 1 m hingga 3 m, diletakkan terus di atas pelantar konkrit.
Key Features
- Seamless body: filament wound in one piece, then laminated.
- Resin matched to the liquid: GP, ISO or vinyl ester.
- See the level: optional semi-transparent strip down the side, or a transparent level tube.
- Corrosion resistant: FRP does not rust like mild steel.
- Built to your drawing: diameter and height made to suit your plant.
Specifications
| Model | FRP-RT-FB |
|---|---|
| Material | FRP (GRP), glass-fibre reinforced polyester or vinyl ester |
| Shape | Round, open top, flat base |
| Dimensions | Diameter 1 m to 3 m (4 m subject to road access); height to your drawing |
| Base | Level concrete plinth at least 250 mm (10 in) above ground |
| Level indicator | Optional semi-transparent strip or transparent level tube |
| Construction | Filament wound body, then laminated |
| Design standard | Designed to BS 4994 / BS EN 13121 and ASTM D3299; engineering calculation on request |
| Corrosion barrier | Optional resin-rich inner layer with polyester veil, or hybrid build with vinyl ester inside and GP outside |
| Working temperature | GP resin 25°C to 40°C. Vinyl ester about 40°C to 75°C, depending on the chemical |
| Nozzle flanges | Standard off-the-shelf HDPE flanges; FRP flanges on request |
| Options | Cover, fiberglass ladder, railing |
| Quality checks | Barcol hardness test, thickness check and leak test on every tank before delivery |
| Warranty | 1 year standard; extended warranty on request |
Example Capacities
| Diameter | Height | Gross volume |
|---|---|---|
| 1 m | 1 m | about 790 L |
| 2 m | 2 m | about 6,300 L |
| 3 m | 3 m | about 21,200 L |
Volumes are approximate and for guidance only. Every tank is built to your sizes.
Applications
- Pre-treatment water holding
- Sludge water holding
- Other holding tanks in wastewater and sewage treatment plants
Resin Selection
- GP (orthophthalic polyester): for water and mild, non-aggressive liquids.
- ISO (isophthalic polyester): a premium polyester with good chemical resistance.
- Vinyl ester: for severe corrosion, including strong acids and alkalis. For solvents, tell us the chemical and we will confirm.
- Hybrid: vinyl ester inside for chemical resistance, GP outside for economy.
Laminate Strength
Test results for the GP laminate used in our Mui Tank range: 103.0 MPa tensile strength (limit 70 min), 182.4 MPa bending strength (limit 100 min) and 0.15% water absorption (limit 1.0 max). Chemical-grade laminate data is available on request.
Installation
- Sit the tank on a level concrete plinth at least 250 mm (10 in) above ground.
- Lift only when empty, using the lifting lugs.
- Support every connecting pipe and valve on its own footing.
What to Tell Us for a Quote
- The chemical or liquid, its concentration and its temperature
- Tank size or drawing, and nozzle positions
- Support type and options such as cover, ladder or railing
FAQ
Can I see the liquid level? Yes. Add a semi-transparent strip down the side or a transparent level tube.
Does it need a stand? No. It sits directly on a level concrete plinth at least 250 mm above ground.
Can it have a cover? Yes, a cover is optional.
Berapa harga tangki air sisa FRP dasar rata? Harga bergantung kepada saiz, resin dan pilihan tambahan. Hubungi Mui Fatt untuk sebut harga terkini.
Adakah Mui Fatt menghantar ke seluruh Malaysia? Ya. Kami menghantar ke seluruh Semenanjung Malaysia, dan ke Sabah serta Sarawak melalui ejen penghantaran. Tempoh siap biasanya 7 hingga 14 hari bekerja.
Ordering and Delivery
Lead time is typically 7 to 14 working days, subject to the production schedule. We deliver across Peninsular Malaysia, and to Sabah and Sarawak through a freight agent. Manufactured by Y.T. Fibreglass Industries Sdn Bhd, a Mui Fatt subsidiary.
Contact Mui Fatt for a quotation: Get a Quote →.
