FRP Sludge Holding Tank
Round FRP tank standing upright, for holding sludge before the filter press in wastewater treatment plants. Diameter 1 m to 3 m, height built to your drawing, set on a concrete plinth.
FRP Sludge Holding Tank - Holds Sludge Before the Filter Press
A round FRP tank that stands upright and holds sludge from the treatment process, for example while it waits to go through the filter press. The filament wound body does not rust, and the resin is matched to the sludge it will hold. In Malay it is often searched as tangki enapcemar FRP.
Ringkasan: Tangki simpanan enap cemar FRP (gentian kaca) berbentuk bulat dan berdiri tegak, untuk menyimpan enap cemar sebelum mesin penapis tekan (filter press). Diameter 1 m hingga 3 m, tinggi mengikut lukisan anda. Dibuat di Malaysia oleh Y.T. Fibreglass Industries Sdn Bhd.
Key Features
- Vertical layout: stands upright, so it takes little floor space next to the filter press.
- Seamless body: filament wound, then laminated.
- Resin matched to the sludge: GP, ISO or vinyl ester.
- Corrosion resistant: FRP does not rust like mild steel.
- Built to your drawing: diameter and height made to suit your plant.
Specifications
| Model | FRP-SHT |
|---|---|
| Material | FRP (GRP), glass-fibre reinforced polyester or vinyl ester |
| Shape | Round, standing vertically |
| Dimensions | Diameter 1 m to 3 m (4 m subject to road access); height to your drawing |
| Support | Level concrete plinth at least 250 mm (10 in) above ground |
| Construction | Filament wound body, then laminated |
| Design standard | Designed to BS 4994 / BS EN 13121 and ASTM D3299; engineering calculation on request |
| Corrosion barrier | Optional resin-rich inner layer with polyester veil, or hybrid build with vinyl ester inside and GP outside |
| Working temperature | GP resin 25°C to 40°C. Vinyl ester about 40°C to 75°C, depending on the chemical |
| Nozzle flanges | Standard off-the-shelf HDPE flanges; FRP flanges on request |
| Options | Cover, fiberglass ladder, railing |
| Quality checks | Barcol hardness test, thickness check and leak test on every tank before delivery |
| Warranty | 1 year standard; extended warranty on request |
Example Capacities
| Diameter | Height | Gross volume |
|---|---|---|
| 1.5 m | 3 m | about 5,300 L |
| 2 m | 3 m | about 9,400 L |
| 3 m | 3 m | about 21,200 L |
Volumes are approximate and for guidance only. Every tank is built to your sizes.
Applications
- Sludge holding before the filter press
- Wastewater and sewage treatment plants
Resin Selection
- GP (orthophthalic polyester): for water and mild, non-aggressive liquids.
- ISO (isophthalic polyester): a premium polyester with good chemical resistance.
- Vinyl ester: for severe corrosion, including strong acids and alkalis. For solvents, tell us the chemical and we will confirm.
- Hybrid: vinyl ester inside for chemical resistance, GP outside for economy.
Laminate Strength
Test results for the GP laminate used in our Mui Tank range: 103.0 MPa tensile strength (limit 70 min), 182.4 MPa bending strength (limit 100 min) and 0.15% water absorption (limit 1.0 max). Chemical-grade laminate data is available on request.
Installation
- Sit the tank on a level concrete plinth at least 250 mm (10 in) above ground.
- Lift only when empty, using the lifting lugs.
- Support every connecting pipe and valve on its own footing.
What to Tell Us for a Quote
- The chemical or liquid, its concentration and its temperature
- Tank size or drawing, and nozzle positions
- Support type and options such as cover, ladder or railing
FAQ
Does it stand upright? Yes. The sludge holding tank stands vertically on a level concrete plinth, which keeps its footprint small next to the filter press.
What size can I order? Diameter 1 m to 3 m, with 4 m subject to road access, and height to your drawing.
Can it have a cover? Yes, a cover is optional.
Berapa harga tangki simpanan enap cemar FRP? Harga bergantung kepada saiz, resin dan pilihan tambahan. Hubungi Mui Fatt untuk sebut harga terkini.
Adakah Mui Fatt menghantar ke seluruh Malaysia? Ya. Kami menghantar ke seluruh Semenanjung Malaysia, dan ke Sabah serta Sarawak melalui ejen penghantaran. Tempoh siap biasanya 7 hingga 14 hari bekerja.
Ordering and Delivery
Lead time is typically 7 to 14 working days, subject to the production schedule. We deliver across Peninsular Malaysia, and to Sabah and Sarawak through a freight agent. Manufactured by Y.T. Fibreglass Industries Sdn Bhd, a Mui Fatt subsidiary.
Contact Mui Fatt for a quotation: Get a Quote →.
