Mui Tank Open Top Round FRP Water Tank, Custom Size
Round open-top fiberglass water tank made to your size when the standard 220 to 880 gallon Mui Tanks do not fit. One-piece seamless FRP with lid, made by Y.T. Fibreglass Industries.
Mui Tank Open Top Round FRP Water Tank, Custom Size
When none of the four standard round Mui Tanks (220 to 880 gallons, 1 m high) fits your space, we make a round open-top fiberglass (FRP) water tank to your size. It is made by Y.T. Fibreglass Industries Sdn Bhd, in the same one-piece seamless FRP with a lid as the standard range.
Ringkasan: Tangki air fiberglass (FRP) Mui Tank bulat terbuka, saiz khas mengikut ruang dan kapasiti anda. Satu keping tanpa sambungan dengan penutup.
Standard Round Sizes
| Model | Capacity | Internal size |
|---|---|---|
| MT-220/C → | 220 gal (1,000 L, 1 m³) | 1.35 m diameter x 1 m high |
| MT-440/C → | 440 gal (2,000 L, 2 m³) | 1.70 m diameter x 1 m high |
| MT-660/C → | 660 gal (3,000 L, 3 m³) | 2.00 m diameter x 1 m high |
| MT-880/C → | 880 gal (4,000 L, 4 m³) | 2.32 m diameter x 1 m high |
Specifications
| Model | MT custom round (SKU FRP-MT-C-CUSTOM) |
|---|---|
| Type | Open top, round, with lid |
| Capacity and size | Made to order |
| Material | Fiberglass reinforced unsaturated polyester (FRP), non-toxic, rust free, UV resistant |
| Construction | One piece, seamless |
| Manufacturer | Y.T. Fibreglass Industries Sdn Bhd |
| Supplier | Mui Fatt Marketing Sdn Bhd (ISO 9001:2015 certified) |
FRP Properties
| Tensile strength | 103 MN/m² (standard minimum 70) |
|---|---|
| Bending strength | 182.4 MN/m² (standard minimum 100) |
| Elastic modulus in bending | 7,906 MN/m² (standard minimum 6,000) |
| Barcol hardness | 50 |
| Water absorption | 0.15% (standard maximum 1.0%) |
Questions About This Tank
What do you need for a quote?
The capacity you need, the diameter and height your space allows, and where the inlet, outlet, overflow and drain should go.
Can I get a closed-top tank instead?
Yes. Closed-top round Mui Tanks come in 1.2 m to 4.0 m diameters. See closed-top custom sizes →.
How should it be installed?
Place it on a flat, level support such as plywood or concrete that carries the whole base. Fit a backing plate outside the tank at the ball valve, use plastic or rubber washers and PTFE tape (no putty or jointing compound), cut pipe holes with a hole saw or sharp punch, support all pipes, and keep the tank away from heaters and lamps.
Berapa harga tangki air fiberglass bulat saiz khas?
Harga bergantung kepada saiz, kuantiti, lokasi penghantaran dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini.
See Also
For installation, care and how to choose between round, square and closed-top tanks, see the full Fiberglass Mui Tank guide →. Certificates are on our certificate page →
Note on units: All gallons on this page are imperial (UK) gallons. 1 m³ = 1,000 litres = 220 imperial gallons. A US gallon is smaller: 1 m³ is about 264 US gallons.
Want to know more about this range? Our free water tank selection guide shows every PE and fiberglass tank at a glance, in seconds, with no details needed: Open the water tank selection guide →
Contact Mui Fatt for a quotation: Get a Quote →
