MuiGrate FRP Pultruded Grating Panels (ML and MFG Series)

MuiGrate FRP pultruded grating panels, ML and MFG series, 25 to 50 mm deep and 50 to 60% open, in widths up to 1,524 mm and lengths up to 6,096 mm. SIRIM certified to BS 4592 Part 4.

SKU :

MFG-ML-RANGE

Quantity :

Send Whatapps

PDF download :

Download PDF

MuiGrate FRP Pultruded Grating Panels (ML and MFG Series)

MuiGrate pultruded grating is made from pultruded FRP (fibreglass) bars, about 65% glass and 35% resin, laid in one direction and tied into panels. It comes in 25, 38 and 50 mm depths with 50 to 60% open area, and is SIRIM certified (licence PM072601) to BS 4592 Part 4.

Pultruded bars are stronger than molded grating in one direction, so they span further between supports. Panels are cut to size and can be supplied with a frame and hinges as trench and sump covers.

Ringkasan: Jeriji FRP pultrusi MuiGrate, kedalaman 25, 38 dan 50 mm, kawasan terbuka 50 hingga 60%. Diperakui SIRIM (BS 4592 Bahagian 4). Tidak berkarat dan boleh dipotong ikut saiz.

Specifications

Type	MuiGrate FRP pultruded grating (bars in one direction)
Glass content	About 65% glass, 35% resin, with surface veil
Panel widths	914, 1,220 or 1,524 mm
Panel lengths	2,438, 3,048, 5,486 or 6,096 mm; cut to size on request
Resin	Isophthalic polyester, vinyl ester or fire-retardant
Colour	Grey, yellow, green
Surface	Plain, gritted or 3 mm chequered plate
Standard	SIRIM product certification to BS 4592 Part 4, licence PM072601
Load use	Pedestrian traffic only (BS 4592)
Made by	Y.T. Fibreglass Industries Sdn Bhd, Port Klang

Models

Model	Depth	Open area	Weight
ML25-25	25 mm	60%	8.1 kg/m²
MFG25-25	25 mm	60%	11.7 kg/m²
MFG38-25	38 mm	58%	17.0 kg/m²
MFG50-25	50 mm	50%	17.4 kg/m²

Why FRP

No rust, no scrap value: FRP does not corrode and has no resale value, so covers are not stolen like steel.
Light: one or two workers lift a cover without machinery.
Non-conductive: safe near pumps, panels and cables.
Long one-way spans: pultruded bars carry load further in one direction than molded grating.

Where It Is Used

Trench and drain covers with frames and hinges
Walkways and platforms in treatment plants
Sump and pit covers

Questions and Answers

Pultruded or molded grating?
Pultruded bars span further in one direction. Molded grating is stronger both ways, takes impact better and is easier to cut around pipes.

Is it SIRIM certified?
Yes. MuiGrate pultruded grating holds SIRIM licence PM072601 to BS 4592 Part 4. A copy is available on request.

Can you supply it with a frame?
Yes, with an FRP or mild steel frame and aluminium, mild steel or stainless steel hinges.

Can vehicles drive over it?
No. MuiGrate FRP grating and covers are designed for pedestrian traffic only, as BS 4592 sets out. Vehicle loads void the warranty unless Mui Fatt has certified the design.

Berapa harga jeriji FRP pultrusi?
Harga bergantung kepada saiz, kuantiti dan pilihan bahan. Hubungi Mui Fatt untuk sebut harga terkini.
