CT 200 Closed Top PE Water Tank 200 Gallon (908 L)
200 gallon (908 L) CT round closed-top PE water tank, slim 850 mm diameter and 2,045 mm high, with a 500 mm hinged cover. Rotomoulded from food-grade LLDPE by Mui Fatt Industries, SIRIM certified and registered with SPAN.
CT 200 Closed Top PE Water Tank 200 Gallon (908 L)
The CT 200 is a slim, round closed-top polyethylene water tank that holds 200 imperial gallons (908 litres, about 0.9 m³). It is 850 mm in diameter and 2,045 mm high, so it fits narrow spaces where a wider tank cannot go. It is rotationally moulded in one piece from food-grade LLDPE by Mui Fatt Industries Sdn Bhd, SIRIM QAS certified to MS 1225-2:2006 (Amd. 1:2011) and registered with SPAN.
Ringkasan: Tangki air PE (poly tank) CT 200, 200 gelen (908 liter), bentuk bulat bertutup yang tinggi dan langsing: diameter 850 mm, tinggi 2,045 mm. Diperbuat daripada LLDPE gred makanan, diperakui SIRIM (MS 1225-2:2006) dan berdaftar dengan SPAN. Sesuai untuk rumah, kedai dan ruang yang sempit.
Specifications
| Model | CT 200 (SKU PE-CT-200) |
|---|---|
| Series | CT, round, closed top (slim) |
| Capacity | 200 gal (908 L), about 0.9 m³ |
| Diameter (D) | 850 mm |
| Height (H) | 2,045 mm |
| Top opening | 500 mm diameter, PE cover with hinges |
| Material | 100% virgin food-grade LLDPE, UV-stabilised |
| Process | One-piece rotational moulding |
| Standard | MS 1225-2:2006 (Amd. 1:2011), SIRIM QAS certified |
| Water authority | Registered with SPAN |
| Warranty | 8 years outdoor, 10 years indoor |
| Manufacturer | Mui Fatt Industries Sdn Bhd |
| Supplier | Mui Fatt Marketing Sdn Bhd (ISO 9001:2015 certified) |
Polyethylene Properties
| Density | 938 kg/m³ |
|---|---|
| Tensile strength | 16 MPa |
| Elongation | More than 200% |
| Flexural modulus | 650 MPa |
| Hardness (Shore D) | 62 |
| Softening point | 117 °C |
Questions About This Tank
Why choose the CT 200 instead of a wider 200 gallon tank?
The CT 200 is only 850 mm wide. It stands tall instead of wide, so it suits narrow corners, small roof spaces and side lanes where floor space is short.
How heavy is it when full?
About 908 kg of water, plus the tank itself. Because it is tall and slim, the base must be flat, firm and support the whole bottom of the tank evenly.
Is it safe for drinking water?
Yes. It is made from food-grade LLDPE, SIRIM QAS certified to MS 1225-2:2006 for cold water storage, and registered with SPAN.
Berapa harga tangki air 200 gelen CT 200?
Harga bergantung kepada kuantiti, lokasi penghantaran dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini.
How should it be installed?
Place it on a level base that supports the whole bottom, join pipes with flexible couplings, keep it away from heaters and other heat sources, and keep the hinged cover closed.
Nearby Sizes
- CT 400-500 closed top, 500 gallon (2,270 L) →
- BM 150-200 round open top, 200 gallon (908 L) →
- SG 150-200 square open top, 200 gallon (908 L) →
For installation, care and how to choose a size, see the full PE water tank guide →. Certificates are on our certificate page →
Note on units: All gallons on this page are imperial (UK) gallons. 1 m³ = 1,000 litres = 220 imperial gallons. A US gallon is smaller: 1 m³ is about 264 US gallons.
