SG 300-400 SEGI Square Open Top PE Water Tank 400 Gallon (1,816 L)
400 gallon (1,816 L) SEGI square open-top PE water tank, 1,550 x 1,550 mm top, 1,390 mm high with cover. Rotomoulded from food-grade LLDPE by Mui Fatt Industries, SIRIM certified to MS 1225-1:2014 and registered with SPAN.
SG 300-400 SEGI Square Open Top PE Water Tank 400 Gallon (1,816 L)
The SG 300-400 is a square open-top polyethylene water tank that holds 400 imperial gallons (1,816 litres) nominal and 300 gallons (1,362 litres) effective. It measures 1,550 x 1,550 mm across the top and 1,390 mm high with the cover on. It is rotationally moulded in one piece from food-grade LLDPE by Mui Fatt Industries Sdn Bhd, SIRIM QAS certified to MS 1225-1:2014 and registered with SPAN.
Ringkasan: Tangki air PE (poly tank) SG 300-400, 400 gelen (1,816 liter), bentuk segi empat dengan penutup (siri SEGI). Diperbuat daripada LLDPE gred makanan, diperakui SIRIM (MS 1225-1:2014) dan berdaftar dengan SPAN. Sesuai untuk tangki air rumah, kedai dan pejabat.
Specifications
| Model | SG 300-400 (SKU PE-SG-300-400) |
|---|---|
| Series | SEGI, square, open top |
| Capacity | 400 gal (1,816 L) nominal; 300 gal (1,362 L) effective |
| Top size (D1) | 1,550 x 1,550 mm |
| Base size (D2) | 1,140 x 1,140 mm |
| Height to top of tank (H1) | 1,190 mm |
| Height to top of cover (H2) | 1,390 mm |
| Material | 100% virgin food-grade LLDPE, UV-stabilised |
| Process | One-piece rotational moulding |
| Standard | MS 1225-1:2014, SIRIM QAS certified |
| Water authority | Registered with SPAN |
| Warranty | 8 years outdoor, 10 years indoor |
| Manufacturer | Mui Fatt Industries Sdn Bhd |
| Supplier | Mui Fatt Marketing Sdn Bhd (ISO 9001:2015 certified) |
Polyethylene Properties
| Density | 938 kg/m³ |
|---|---|
| Tensile strength | 16 MPa |
| Elongation | More than 200% |
| Flexural modulus | 650 MPa |
| Hardness (Shore D) | 62 |
| Softening point | 117 °C |
Questions About This Tank
What do 300 and 400 mean in SG 300-400?
300 gallons is the effective capacity you can use. 400 gallons is the nominal capacity.
How heavy is it when full?
About 1,816 kg of water at nominal capacity, plus the tank itself. The base must be flat and support the whole bottom of the tank evenly.
Is it safe for drinking water?
Yes. It is made from food-grade LLDPE and SIRIM QAS certified to MS 1225-1:2014 for cold water storage, and registered with SPAN.
Berapa harga tangki air 400 gelen SG 300-400?
Harga bergantung kepada kuantiti, lokasi penghantaran dan aksesori yang diperlukan. Hubungi Mui Fatt untuk sebut harga terkini.
How should it be installed?
Place it on a level base that supports the whole bottom, join pipes with flexible couplings, keep it away from heaters and other heat sources, and always fit the cover.
Nearby SEGI Sizes
- SG 150-200, 200 gallon (908 L) →
- SG 200-250, 250 gallon (1,135 L) →
- SG 250-300, 300 gallon (1,362 L) →
For installation, care and how to choose a size, see the full PE water tank guide →. Certificates are on our certificate page →
Note on units: All gallons on this page are imperial (UK) gallons. 1 m³ = 1,000 litres = 220 imperial gallons. A US gallon is smaller: 1 m³ is about 264 US gallons.
