FRP Refrigerated Truck Skin Panel 1 mm
FRP skin panel, 1 mm thick (up to 1.8 mm), for the inner and outer skins of refrigerated truck and van bodies. Light, impact resistant and rust free, 1,200 to 2,200 mm wide, in lengths or rolls.
FRP Refrigerated Truck Skin Panel 1 mm
This FRP skin panel is a 1 mm fibreglass composite sheet for the bodies of refrigerated trucks and vans. Bonded over insulation, it forms a light, smooth and rust-free skin that resists impact and washes clean. Lighter than metal skins at 1.8 g/cm³, it helps keep body weight down. It comes 1,200 to 2,200 mm wide in 4, 8 or 12 ft lengths or in rolls, and in 1.2, 1.5 and 1.8 mm.
Ringkasan: Panel kulit FRP setebal 1 mm untuk badan lori dan van berpendingin. Ringan, tahan hentaman dan tidak berkarat, lebar 1,200 hingga 2,200 mm, dibekalkan dalam panjang atau gulungan.
Specifications
| Product | FRP skin for refrigerated truck bodies |
|---|---|
| Material | FRP composite sheet (thermoset plastic reinforced with glass fibre) |
| Thickness | 1 mm (also 1.2, 1.5 and 1.8 mm) |
| Width | 1,200 to 2,200 mm |
| Length | 4 ft, 8 ft or 12 ft per piece, or in rolls |
| Specific gravity | 1.8 g/cm³ |
| Colour | White or blue |
Material and Features
- Light: lower body weight than metal skins
- Impact resistant: copes with loading knocks
- Rust free: no corrosion from condensation or road salt
- Thermal resistance: helps keep the cold in
Where It Is Used
- Refrigerated truck and van bodies
- Insulated delivery boxes
- Reefer container repairs
- Mobile cold storage units
For Body Builders
Supplied in rolls for long panels with fewer joints. Tell us the body length, height and quantity, and we will advise width and thickness.
Frequently Asked Questions
What thickness is the truck skin panel?
1 mm standard, also 1.2, 1.5 and 1.8 mm.
Why use FRP for truck bodies?
It is light, impact resistant and does not rust.
Can it be supplied in rolls?
Yes, as well as 4, 8 or 12 ft lengths.
What colours are available?
White or blue.
Berapa harga panel kulit lori sejuk FRP?
Harga bergantung kepada ketebalan, saiz dan kuantiti. Hubungi kami untuk harga terkini.
