FRP Formwork Board Sheet 1 mm, 1,200 to 2,200 mm Wide
Fibreglass (FRP) composite sheet, 1 mm thick (1.2, 1.5, 1.8 mm also), for facing concrete formwork boards. 1,200 to 2,200 mm wide in 4, 8 or 12 ft lengths. Does not rot like plywood or rust like steel.
FRP Formwork Board Sheet 1 mm, 1,200 to 2,200 mm Wide
This FRP formwork sheet is a 1 mm thick fibreglass composite sheet used to face concrete formwork boards. A smooth, hard FRP face gives a cleaner concrete finish and stands up to water and cement better than bare plywood, and it does not rust like steel forms. The sheet is 1,200 to 2,200 mm wide, in 4, 8 or 12 ft lengths or in rolls, and also comes in 1.2, 1.5 and 1.8 mm.
Ringkasan: Kepingan komposit FRP setebal 1 mm untuk permukaan papan acuan konkrit. Lebar 1,200 hingga 2,200 mm, panjang 4, 8 atau 12 kaki. Tidak reput seperti papan lapis dan tidak berkarat seperti keluli.
Specifications
| Product | FRP sheet for formwork boards |
|---|---|
| Material | FRP composite sheet (thermoset plastic reinforced with glass fibre) |
| Thickness | 1 mm (also 1.2, 1.5 and 1.8 mm) |
| Width | 1,200 to 2,200 mm |
| Length | 4 ft, 8 ft or 12 ft per piece, or in rolls |
| Specific gravity | 1.8 g/cm³ |
| Colour | White or blue |
Material and Features
- Smooth face: helps give a clean concrete surface
- Water and alkali resistant: stands up to wet cement
- Light: 1.8 g/cm³, lighter than metal facing
- Easy to cut: trim on site with standard tools
Where It Is Used
- Facing plywood or timber formwork boards
- Precast concrete moulds
- Column and wall forms
- Other site boards that get wet
Sheet Choice
1 mm suits most formwork facing. Choose 1.5 or 1.8 mm where the face takes more wear. Tell us the board size so we can suggest the width and length with the least waste.
Frequently Asked Questions
What thickness is the formwork sheet?
1 mm standard, also 1.2, 1.5 and 1.8 mm.
What widths and lengths are available?
1,200 to 2,200 mm wide, in 4, 8 or 12 ft lengths or in rolls.
Why face formwork with FRP?
FRP is smooth, water resistant and does not rot or rust, so the face lasts longer than bare plywood.
What colours are there?
White or blue.
Berapa harga kepingan FRP untuk papan acuan?
Harga bergantung kepada ketebalan, saiz dan kuantiti. Hubungi kami untuk harga terkini.
